Zidoo UHD2000 Specification

ModelUHD2000
ColorBlack
ShellAviation Aluminum alloy case
CPURealtek RTD1296 ARM Cortex-A53 quad-core
OSAndroid 7.1 + OpenWRT (NAS) dual system running simultaneously
GPUARM T820 MP3(3-core)
RAM4GB DDR4
Internal Storage32GB eMMC
Audio decoding chipXMOS (8 logic cores) supports native decoding DSD512,768KHz@32bit PCM
ESS 9038 Professional Audio DAC
WIFIIEEE 802.11 a/b/g/n/ac 2×2 MIMO 867Mpbs
Ethernet1 * RJ-45 (10/100/1000Mbps)
BluetoothBT4.1
HDMI outputHDMI 2.0a Support 4K@60fps 10Bit
HDMI 1.4 (Audio Only audio pass through)
HDMI inputHDMI 2.0 supports 4K@30fps
Video decodingHDR
10-bit HEVC/H.265 up to 4K@60fps
VP9 up to 4K@60fps
H.264 up to 4K@24fps
Video playbackSupport 4K ultra-high definition media files
automatic frame rate switching
MVC 3D playback
subtitles download
ASS/SSA/SUP special effect subtitles
Audio decodingSupports high-definition panoramic sound audio pass through and stereo decoding output
XMOS+ESS 9038 hardware decoding
Redesigned Native Player
Audio ports1 * SPDIF (2CH, 5.1CH)
1 * coaxial output
1 * RCA left and right channel
1 * XLR left and right channel balance
Analog audioFrequency range: 20Hz-20KHz +/-0.35dB
signal-to-noise ratio (SNR)>120dBrA
Total harmonic distortion + noise (THD+N) < 0.0003%
output level (XLR) 4.5 ± 0.4Vrms.(RCA) 2.2±0.2Vrms
dynamic range (DNR) >122dB channel resolution (Crosstalk) >128dBrA
Storage1 * USB3.0
2 * USB2.0
1 * Type-C
Hard Disk2 * SATA3.0 3.5-inch hard drive bay (without hard drive)
Other interface1 * IR infrared input
1 * IR infrared output
1 * RCA composite video
1 * RS232
Power supplyAC 110~120/220~240V 50/60Hz (built-in linear power supply)
Accessories1 * Media Player
1 * Remote Control
1 * Power Cable
1 * HDMI cable
2 * Antennas
1 * User Manual
Dimension (L x W x H)430 x 312 x 72 mm (antennas and foot pad are not calculated)
